DTAMW-2 DTAHW-2系列（12x12 防水轻触开关）

Contact Rating:50mA, 24V DC
Contact Resistance:100mΩ max.
InsulationResistance:100MΩ min. 250V DC
Dielectric Strength:250V AC/1 minute
Operating Force:160±50gf, Brown(N)
                           260±50gf, Red(R)
                           320±80gf, Salmon(S)
                           520±130gf, Yellow(Y)
Travel:0.4mm
Operating Life:300,000 cycles for 520/320gf
                       1,000,000 cycles for 260/160gf
Operating Temp:-40°C ~ +85°C
Storage Temp:-40°C ~ +85°C

Audio, OA equipment 音频、办公自动化设备
Instrumentation 仪器仪表
Industrial 工业
